Stainless Steel Chainwheels In Stock

Item Name:

Trumbull Stainless Steel Chainwheels

Description:

TRUMBULL stainless steel chainwheels provide safe, easy operation of overhead valves with a simple pull of the chain. Their universal design allows for mounting directly to the valve stem or clamping to an existing handwheel.



Constructed from Type 316 investment-cast stainless steel, these chainwheels are ideal for corrosive environments such as chemical processing, outdoor installations, and saltwater applications. Each unit includes attachment hardware, and pocket-style models are designed for use with smooth, welded link (proof coil) chain.



Chainwheels furnished standard with "B" attachment sets (see above chart)

For optional ranges, using "A" or "C" sets (see tables below)



For direct mounting to shaft only:
Stainless Steel Bushing, machined by customer
Stainless Steel Bushing, machined by Trumbull



Optional hardware attachment sets are available to fit different ranges of handwheels



D suffix denotes "Disc", used in lieu of standard clamping hardware
Shipping Time: 1-3 Business Day
Express ship options available
Specifications
Part # Size No. Diameter of
Chainwheel 		Range of Handwheels
Chainwheels will fit 		Length of Chain
Required
(2x Drop)
367-1825 TRS-4D* 4-1/8" ** 1-1/2" I.D. TO 4-1/2" O.D. ** Plus 1 ft. Add to RFQ
367-1830 TRS-6D* 5-7/8" ** 2-1/8" I.D. TO 6-1/4"" O.D. ** Plus 1 ft. Add to RFQ
367-1833 TRS-8B 8" ** 7-1/2" I.D. TO 10-1/2" O.D. ** Plus 1-1/2 ft. Add to RFQ
367-1845 TRS-12B 11-5/8" ** 8-1/2" I.D. TO 13-1/2" O.D. ** Plus 1-1/2 ft. Add to RFQ
367-1850 TRS-15B 15-3/16" ** 9-1/2" I.D. TO 17-1/2" O.D ** Plus 2 ft. Add to RFQ
367-1860 TRS-22B 22-1/4" ** 13" I.D. TO 25" O.D. ** Plus 3 ft. Add to RFQ
367-1870 TRS-29B 29-1/4" ** 17-3/4"" I.D. TO 32" O.D. ** Plus 4 ft. Add to RFQ
Chain & Link
Part # Description
367-1815 TRS-316
316 Stainless Steel Welded Link Machine Chain, Trumbull Calibrated 		Add to RFQ
367-1816 TRS Series
Stainless Steel Connecting Link (1 Required Per Chainwheel) 		Add to RFQ
Overall Assembly Dimensions
Size Wheel O.D. Height Width Depth
TRS-4 4-1/8" 6-1/4" 4-5/8" 2-3/8" Add to RFQ
TRS-6 5-7/8" 7-1/16" 6-3/16" 2-5/8" Add to RFQ
TRS-8 8" 9" 8-7/16" 2-3/4" Add to RFQ
TRS-12 11-5/8" 13-1/8" 12" 2-3/4" Add to RFQ
TRS-15 15-3/16" 16-1/4" 15-5/8" 2-3/4" Add to RFQ
TRS-22 22-1/4" 22-1/4" 22-5/8" 2-3/4" Add to RFQ
TRS-29 29-1/4" 29-1/4" 29-1/2" 2-3/4" Add to RFQ
Handwheel O.D. Ranges with Optional "A" Attachment Set
Size Min. O.D. Max. O.D.
TRS-4 n.a. n.a. Add to RFQ
TRS-6 n.a. n.a. Add to RFQ
TRS-8 6" 8" Add to RFQ
TRS-12 7" 11" Add to RFQ
TRS-15 8" 15" Add to RFQ
TRS-22 11" 22-1/2" Add to RFQ
TRS-29 16" 29" Add to RFQ
Handwheel O.D. Ranges with Optional "C" Attachment Set
Size Min. O.D. Max. O.D.
TRS-4 n.a. n.a. Add to RFQ
TRS-6 n.a. n.a. Add to RFQ
TRS-8 12-1/4" 15-1/2" Add to RFQ
TRS-12 13-1/4" 18-1/2" Add to RFQ
TRS-15 14-1/8" 23" Add to RFQ
TRS-22 17-1/2" 30" Add to RFQ
TRS-29 22-1/2" 37" Add to RFQ
